A question we sometimes get is how well a radar operates in a horizontal position. The manufacturer will tell you to mount it upright if you ask them. However, some e-bike rack mounts offer an integrated radar that is mounted horizontally and made by the same manufacturer (e.g., Specialized Turbo Vado). Did they rotate the electronics in a special build of the radar? The short answer is no. They use the same RVR315 radar turned sideways and power it directly without using a battery. So then, what is the real difference and impact of a vertical orientation and a horizontal orientation of a typical bike radar? If you want to learn more about that answer, read on.

Bike radars use a Doppler radar projection that is oval in shape. This means that when the beam is turned sideways the beam becomes narrower to the sides and larger top to bottom. Each manufacturer is a little different, so we will reference the common, and albeit older, radar system when referring to detection ranges and beam sizes. Radar returns can be affected by a number of factors, but the quoted ranges should be relatively accurate and represent the typical average performance of bike radars for the purpose of this article.

With that in mind, at 100 feet (the distance between two telephone poles), the beam is about 70 feet wide using a standard vertical orientation. For reference, a typical road lane is about 10-12 feet wide. When turned sideways at the same distance, the beam would be about 30-40 feet wide. Initial vehicle detection of typical radar usage is usually between 250-400 feet. At a distance of only two telephone poles apart (200 feet), a standard vertical orientation would project a beam of 120-140 feet wide. A horizontally oriented beam would project a beam roughly 60-80 feet wide. As the distance increases, so does the beam width in both cases.

It is important to understand that the orientation alone does not affect the distance that the radar detects the returns. In a straight line, the distance remains the same regardless of the orientation. The detection distance is a byproduct of the sensors and radar power, the position of the target within the radar cone, and the relative closure rate of the target to the radar projector. Objects closer to the edge of the radar's projection cone provide weaker returns. When a radar is rotated sideways, the cone becomes narrower. As mentioned, when straight on, there will be no difference, but it will affect the return around tight corners (more to follow).

Let's look at some visual examples. In the first example, the car is only two car lengths behind the rider. At a speed of 15 mph (24 kph) that means the car would be less than 1.4 seconds behind the rider (too close). Looking over one's shoulder, the view would be something like this:

Using a normal vertical orientation, the radar cone would encompass the car like shown below, even at this short distance.

Unlike this image, the beam coverage would actually extend well past the car, but it should be clear that even when riding to one side of the road, the radar projection cone solidly covers the entire car.

When the radar is mounted horizontally, it compresses the lateral (side to side) beam projection. The car is still fully painted by the radar beam when directly behind, but in a tight hairpin turn at this distance the car would start to leave the coverage and the result would be an intermittent contact. That said, the detection would have already occurred long before, and the rider would be aware that someone is right on their tail at this point.

From a top-down view, the difference in the horizontal orientation projection cone is more pronounced, but still covers the car well enough to return a strong signal even at this close distance.

More likely, a typical unexpected detection of a car around a hairpin turn would be at about five car lengths away - roughly 75-80 feet. The view over the shoulder would still place the car very close at even a slow 25 mph vehicle speed (remember, it's a tight turn).

Under normal conditions with a normal vertical radar orientation, the cone would easily cover the car in this situation as well. Remember, this is only 75 feet.

At the same 75 feet with a horizontal orientation, the beam would also cover the car completely. Even if turned very tightly and the beam only partially covered the car, the radar would still provide adequate returns for a reading (assuming there is closure).

In conclusion, there are differences in vertical and horizontal orientation, but a horizontal position is still functionally equivalent in most meaningful cases. Where horizontal orientation has weaker performance is during very tight turns. Where would this matter? If a car was coming on fast enough that it wasn't initially detected before a tight and slow turn, and the approaching rally driver was entering a 25 mph hairpin turn at 50 mph, the radar would have less time to warn the rider, but it doesn't mean there would not be any warning. In this scenario, if the car was approaching that fast, and wasn't detected prior to the turn, the difference between the two orientations would most likely result in a difference of a fraction of a second. In other words, don't rely solely on a radar in these situations.

When using BUP horizontal mounts, always use the safety tether kit. Not only does this prevent accidental loss, it is a requirement to ensure that the radar does not unlatch itself. Without the tether band, the natural gravity and g-forces while riding will unlatch the radar if the band is not attached and clipped to the arm.
